The main result expected is the development of a demonstration waste treatment facility that allows authorities to comply with european directives regarding waste management with annual capacity for 30.000 tons of rsu rejection. |
The main result expected is the development of a demonstration waste treatment facility that allows authorities to comply with European directives regarding waste management (Directive 1999/31 EC and Directive 2006/12/EC) with annual capacity for 30.000 tons of RSU rejection. Beyond the expected results for each of the actions, the final outcome of the projecte is established from the residual prognosis territory. See attached tables:
|
- Residual starting situation. (2008).
| Rejection fraction generated by the participating municipalities intended for final treatment | 40.000 Tons/year (Destined to multiple finalist installations) |
| Data provided by the Catalan Waste Agency “Agencia de Residus de Catalunya” | |
- Expected Waste Situation (2012).
| Rejection fraction generated by the participating municipalities intended to KDV unit | 40.000 Tons/year |
| Produced Diesel | 15.000 Tons/year |
| Unit KDV rejection | 3.000 Tons/year (Destined to finalist installations) |
| Emissions savings | 44.000 Tons CO2/year |
| Estimates made by SANEA | |
The Project plans the certification of a fuel Diesel A that complies with the regulation EN590.
| Parameter | According to EN 590 | Unit | Method |
| Cetane index Density at 15ºC |
> 46 Between 820 and 845 |
Kg/m3 | ASTIM 4737-04 ASTM D4052-96(2002) e1 |
| Policyclic Aromatic Hydrocarbons | <11 | % m/m | UNE-EN 12916-07 |
| Sulfur | <0,10 | % m/m | IP 336-04 |
| Distillation at 760 mmHg | ASTM D 86-09 | ||
| 65% collected 80% collected |
>250 | ºC ºC |
|
| 85% collected 95% collected |
<350 <360 |
ºC ºC |
|
| Kinematic Viscosity at 40ºC Inflammation point |
Between 2,00 and 4,50 >55 |
mm2/s ºC |
ASTM D 445-06 ASTIM D 93-08 |
| Cold Filter Plugging Point Micro-carbonaceous residue. |
<-10 <0,30 |
ºC % m/m |
UNE-EN 116/AC-99 ASTIM D 4530-07 |
| Lubricity Water |
<460 <200 |
µm mg/kg |
UNE-EN 12662-99 UNE-EN ISO 6245-03 |
| Total contamination Ash |
<24 <0,01 |
mg/kg % m/m |
UNE-EN 12662-99 UNE-EN ISO 6245-03 |
| Copper Strip Corrosion Oxidation stability |
1 Class <25 |
g/m3 | ASTM D 130-04E1 ASTM D 2274-03a |
| Color Transparency and gloss |
L.2 Meets |
ASTM D 1500-07 ASTIM D 1500-07 |
